MINILHA CURVA PINO ROSCADO ALLOY

SCREW PIN ANCHOR SHACKLE G-209	SIZE/INCH	PIN/INCH	WLL/TON	WT/KGS
	3/16	1/4	0.30	0.023
	1/4	5/16	0.50	0.054
	5/16	3/8	0.75	0.086
	3/8	7/16	1.00	0.141
	7/16	1/2	1.50	0.172
	1/2	5/8	2.00	0.286
	5/8	3/4	3.25	0.626
	3/4	7/8	4.75	1.021
	7/8	1	6.50	1.533
	1	1-1/8	8.50	2.413
	1-1/8	1-1/4	9.50	3.089
	1-1/4	1-3/8	12.00	4.309
	1-3/8	1-1/2	13.50	6.010
	1-1/2	1-5/8	17.00	7.801
	1-3/4	2	25.00	13.78
	2	2-1/4	35.00	20.41
	2-1/2	2-3/4	55.00	38.90

MANILHA CURVA PINO ALLOY C/PORCA E CUPILHA

BOLT TYPE ANCHOR SHACKLE G-2130	SIZE/INCH	PIN/INCH	WLL/TON	WT/KGS
	1/2	5/8	2.00	0.358
	5/8	3/4	3.25	0.762
	3/4	7/8	4.75	1.234
	7/8	1	6.50	1.792
	1	1-1/8	8.50	2.776
	1-1/8	1-1/4	9.50	3.751
	1-1/4	1-3/8	12.00	5.312
	1-3/8	1-1/2	13.50	7.181
	1-1/2	1-5/8	17.00	9.435
	1-3/4	2	25.00	15.38
	2	2-1/4	35.00	23.70
	2-1/2	2-3/4	55.00	44.57
	3	3-1/4	85.00	69.85
	3-1/2	3-3/4	120.00	120.00
	4	4-1/4	150.00	153.50

MINILHA RETA PINO ROSCADO ALLOY

SCREW PIN CHAIN SHACKLE G209	SIZE/INCH	PIN/INCH	WLL/TON	WT/KGS
	3/16	1/4	0.30	0.022
	1/4	5/16	0.50	0.050
	5/16	3/8	0.75	0.077
	3/8	7/16	1.00	0.109
	7/16	1/2	1.50	0.181
	1/2	5/8	2.00	0.268
	5/8	3/4	3.25	0.549
	3/4	7/8	4.75	1.020
	7/8	1	6.50	1.433
	1	1-1/8	8.50	2.155
	1-1/8	1-1/4	9.50	3.062
	1-1/4	1-3/8	12.00	4.110
	1-3/8	1-1/2	13.50	5.275
	1-1/2	1-5/8	17.00	7.235
	1-3/4	2	25.00	12.14
	2	2-1/4	35.00	19.19
	2-1/2	2-3/4	55.00	32.55

MANILHA RETA PINO ALLOY C/PORCA E CUPILHA

BOLT TYPE CHAIN SHACKLE G-2150	SIZE/INCH	PIN/INCH	WLL/TON	WT/KGS
	1/2	5/8	2.00	0.340
	5/8	3/4	3.25	0.667
	3/4	7/8	4.75	1.143
	7/8	1	6.50	1.746
	1	1-1/8	8.50	2.517
	1-1/8	1-1/4	9.50	3.447
	1-1/4	1-3/8	12.00	4.903
	1-3/8	1-1/2	13.50	6.237
	1-1/2	1-5/8	17.00	8.392
	1-3/4	2	25.00	14.24
	2	2-1/4	35.00	21.21
	2-1/2	2-3/4	55.00	38.56
	3	3-1/4	85.00	56.35
	3-1/2	3-3/4	120.00	110.00
	4	4-1/4	150.00	138.50
